Appointment
The UTAB-20 battery tester is designed for automatic control discharge of batteries with nominal voltages of 3 and 12 volts, as well as for determining the internal resistance and short-circuit current of the battery.
Testing is performed by control discharge of batteries with a stabilized current or stabilized power, to the set end voltage.
The device can be used as an electronic load during testing of power supplies and chargers.
Field of application
- service centers for battery maintenance;
- car service stations;
- service stations of motor transport enterprises;
- battery manufacturers.
Technical characteristics:
|
Parameter naming |
Parameter value |
|
Rated supply voltage |
220 volts, ~ 50 Hz. |
|
Maximum input voltage from the battery |
16.2 Volts. |
|
Minimum input voltage from the battery |
2.5 Volts. |
|
Maximum discharge current: |
30.0 Ampere |
|
Minimum discharge current |
0.1 Ampere |
|
Maximum discharge power |
480 W |
|
Discreteness of the discharge current setpoint |
0.1 Ampere |
|
Discreteness of the final discharge voltage setpoint |
0.1 Volt |
|
Discreteness of the discharge power setpoint |
1 W |
|
Maximum value of the controlled capacity |
999 Ah |
|
Максимальне значення контрольованої енергії |
9.99 kWh |
|
The maximum value of the battery internal resistance to be determined |
999 mOhm |
|
Degree of protection according to DSTU EN 60529:2018 |
IP20 |
|
Dimensions (W×H×D) |
290×80×233 mm |
|
Weight, no more than |
3 kg |
To test more powerful batteries, we recommend reviewing UTAB 6-48/65
